Asphalt Plant 160t/h, Item AMP2000-C 2300kg per batch mixing system

Asphalt Mixing Plant

Inquiry

The AMP2000-C stationary asphalt plant has a mixing capacity of 2300 kg/batch, which can meet the needs of medium-sized projects. A highly abrasion resistant material is used on the blade and liner in the mixing cylinder, ensuring an excellent wear resistance. A thermal oil heater is installed on the exterior of the mixing cylinder to ensure the material temperature, which is critical for the production of modified asphalt, rubber asphalt and hot recycling materials.

This kind of mixing equipment has a large output and is popular with customers carrying out large and medium-sized projects. The equipment was purchased by Saudi Arabian customers in 2004, and then by Kazakhstan and Algeria in 2006, when the purchases amounted to more than $1 million, demonstrating the excellent processing capacity and stability. It will operate normally in extremely hot environments, without sacrificing its efficiency. Shown below is basic information, for more information, please do not hesitate to contact us.

• Maximum output: 160t/h
• Mixing capacity: 2300kg/batch
• Total installed capacity (excluding finished product bin): 430kw
• Total floor area: 45x36=1620m²
• Maximum fuel consumption: 6.2kg/t
• Maximum dust emission concentration: 75 mg/Nm³
• Finished product temperature: 130-160℃
• Maximum ambient noise: 85dB(A)
• Maximum ear noise: 70dB(A)
• Dust removal mode: pulse bag filter
• Fuel: diesel, heavy oil and gas

• The asphalt tank, finished product bin and powder bin can be mounted according to specific project needs.
• Different fuel types can be chosen, including diesel, heavy oil and gas.
• An opening was designed on the mixing cylinder to prepare for adding more accessory equipment, such as PRD hot recycling equipment, SMA wood fiber adding device and more.
