Asphalt Plant 180t/h, Item AMP2500-C 2500kg per batch mixing system

Asphalt Mixing Plant

Inquiry

The AMP2500-C stationary asphalt plant can be packed into containers for easy transportation. Xuetao asphalt plant's feature a stable performance and excellent adaptability to meet different working conditions. The quality of finished materials meets all construction requirements of urban roads, airports and high-grade highways. Our company has a professional installation after-sales team. After the equipment arrives at the site, our company will send experienced installation engineers to the site to guide installation and train the relevant operators until they can independently operate the equipment.

• Maximum output: 180t/h
• Mixing capacity: 2500kg/batch
• Total installed capacity (excluding finished product bin): 494kw
• Total floor area: 40x40=1600m²
• Maximum fuel consumption: 6.2kg/t
• Maximum dust emission concentration: 75 mg/Nm³
• Finished product temperature: 130-160℃
• Maximum ambient noise: 85dB(A)
• Maximum ear noise: 70dB(A)
• Dust removal mode: pulse bag filter
• Fuel: diesel, heavy oil and gas

• The asphalt tank, finished product bin and powder bin can be mounted according to specific project needs.
• Different fuel types can be chosen, including diesel, heavy oil and gas.
• An opening was designed on the mixing cylinder to prepare for adding more accessory equipment, such as PRD hot recycling equipment, SMA wood fiber adding device and more.
