Asphalt Plant 400t/h, Item AMP5000-C 5300kg per batch mixing system

Asphalt Mixing Plant

Inquiry

The AMP5000-C stationary asphalt plant has a mixing capacity of 5000 kg/batch, and a maximum output of 400 t/h. It has a stable quality and is cost-effective. The equipment can simultaneously supply two pavers when paving high-grade roads, making it suitable for airport and high-grade highway pavement construction. Xuetao launched this equipment as early as 2007, and has been consistently updating it in the years to follow. The plant was sold to China Railway 14 Bureau Group Co., Ltd. in 2010 and was used for highway construction. During the five-year period, it completed about 1.3 million tons of asphalt. Over the few years, the company purchased more of this equipment from us through open tendering. Shown here is basic information, and if you would like to know more, please contact us directly.

• Maximum output: 400t/h
• Mixing capacity: 5300kg/batch
• Total installed capacity (excluding finished product bin): 991kw
• Total floor area: 68x40=2720m²
• Maximum fuel consumption: 6.2kg/t
• Maximum dust emission concentration: 75 mg/Nm³
• Finished product temperature: 130-160℃
• Maximum ambient noise: 85dB(A)
• Maximum ear noise: 70dB(A)
• Dust removal mode: pulse bag filter
• Fuel: diesel, heavy oil and gas

• The asphalt tank, finished product bin and powder bin can be mounted according to specific project needs.
• Different fuel types can be chosen, including diesel, heavy oil and gas.
• An opening was designed on the mixing cylinder to prepare for adding more accessory equipment, such as PRD hot recycling equipment, SMA wood fiber adding device and more.
